Size | 86 mm |  |  | Nema | 34 |  |
Length (L) | 115 mm |  |  | Current/Phase | 5.5 A |  |
Holding Torque | 7 Nm |  |  | Step Angle | 1.8 ° |  |
Rated Voltage | 2.6 Vdc |  |  | Resistance/Phase | 0.46 Ohm |  |
Inductance/Phase | 4.5 mH |  |  | Rotor Inertia | 2700 gcm2 |  |
Detent Torque | 0.12 Nm |  |  | N° of Leads | 4 |  |
Weight | 2.8 Kg |  |  | Encoder | Optical - Incremental 1000 CPR / 2 Channel |  |
Step Angle accuracy | ± 5 % |  |  | Insulation Class | B |  |
Operating Temperature | - 20°C + 50°C |  |  | Max. Temp. Rise (rated current, 2-phase on) | 80°C Max °C |  |
Radial Play (450g load) | 0.02 Max mm |  |  | Axial Play (450g load) | 0.08Max mm |  |
Max. Radial Force (20mm from flange) | 220 N |  |  | Max. Axial Force | 60 N |  |
Dielectric Strength (for 1min.) | 750 VAC |  |  | Insulation Resistance (min.500 VDC) | 100 Mohm |  |
